wood pellet making machinery

Payment Terms: T/T,L/C,WU
Place of Origin: Shandong, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: XGJ
Production Capacity: 300 Set/Sets per Month
Delivery Date: within 7 working days
Pellet size: 4-12mm
Dimension(L*W*H): 2600x1300x2300mm
type: Vertical Ring Die
Means of Transport: Ocean,Land
Packing: Iron Steel Box
Application: Biomass-energy fules plant,...
Power: 90kw
Weight: 5.3t
Material: Alloy Steel

Efficiency high overload capacity, low noise, small vibration, reliable structure ,beautiful appearence

Specifications

wood pellet making machinery
1. CE ISO SGS certification
2. suitable various materials
3. long working time press pellets

I. Introduction

Our company produces the SKJ series pellet mill, which absorb elite of Germany KAHL pellet mill,

the heart parts "die" and "rollers" are made by high alloy steel wear resistant material according to different materials, have long lifetime.

The transmission parts adopt auto differential, drum juncture or universal joint drive.

Little noise, low energy consumption, high efficiency and easy operation the series pellet mills were developed elaborately to be our patent products.

The products are applied to large-sized, medium-sized and small bio-mass energy fuel plants, wood working factory, municipal refuse cleaning plant, organic fertilizer plant, chemical plant, animal feed plant and fishery etc.

With low investment, quick effective, no risk, our pellet mills are the most ideal compact shaped equipments.

II. Main Characteristics

The wood pellet machine here we are introducing is our flat die type wood pellet machine. The technology of this type wood pellet machie was adopted from Germany. After lots of improvement in the passed years, now they are our patent producs which has lots of advantages for making biomass pellets.

For our SKJ3- Series wood pellet machine, they have 3 rollers and one flat die inside of the pellet machine. The reduction frition between them make their lifetime longer than normal pellet machine.

Our SKJ Series flat die wood pellet machine has CE, SGS etc certificates which is widely acceptabel in Europe, America, Asia and so on areas all over the world.

Our wood pellet machine can be used for making wood chips, sawdust, rice husk, papers, stalk, straw, plstic, peanut shell and so on materials into biomass pellets. Besides this, they can also make fertilizer pellets and animal feed pellets.

The diameter of the pellets made by our wood pellet machine can be 2-15mm. Bigger models of our pellet machine can also be used or making briquettes, the max dimeter of briquettes is 30mm.

The following is the simple specifications for our SKJ Series wood pellet mills.





Model

Power (kw)

Capacity (t/h)

Product spec (mm)

Weight (t)

Dimension (mm)

SKJ2-150

7.5

0.02-0.05

Φ4-6

0.20

1280X480X820

SKJ2-200

11

0.05-0.1

Φ4-6

0.26

1300x500x850

SKJ2-250

15

0.1-0.3

Φ4-6

0.56

1400x600x1000

SKJ2-280

22

0.2-0.4

Φ4-8

0.70

1720x600x1200

SKJ2-300

30

0.3-0.5

Φ4-8

 0.76

1800x670x1600

SKJ3-350

37

0.4-0.6

Φ4-10

2.2

1900x850x1750

SKJ3-450

55

0.5-0.8

Φ4-10

4.3

2300×1100×1900

SKJ3-550

90

0.8-1.2

Φ4-12

5.5

2350×1000×2050

SKJ3-800

130

1.5-2.5

Φ4-12

6.8

3200×1250×2700

SKJ4-1200

280-320

3-5

Φ4-12

19

3800×1700×4200

XGJ560

90+3+0.25+1.5

1-1.5

Φ4-12

6.1

2600x1300x2300

XGJ720

160+1.5+0.37+1.5

1.5-2.5

Φ4-12

7

2900x1300x2400

XGJ850

220+3+0.37+2.2(2-850)

220+3+0.55+2.2(3-850)

2.5-3

Φ4-12

14.5

3300x1400x3100

XGJ920

315+5.5+3+0.55+3

3-4

Φ4-12

18

3800x1680x3400

XGJ1050

360

5-6

Φ4-12

23
