EFB pellet machine/palm pellet mill machine

Payment Terms: T/T,L/C,WU
Place of Origin: Shandong, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: XGJ
Production Capacity: 300 Set/Sets per Month
Delivery Date: within 7 working days
Pellet size: 4-12mm
Dimension(L*W*H): 2600x1300x2300mm
type: Vertical Ring Die
Means of Transport: Ocean,Land
Packing: Iron Steel Box
Application: Biomass-energy fules plant,...
Power: 90kw
Weight: 5.3t
Material: Alloy Steel

Efficiency high overload capacity, low noise, small vibration, reliable structure ,beautiful appearence

Specifications

efb wood pellet machine
1.CE ISO9001:2008 SGS certification
2.high efficiency low consumption
3.suitable various materials

Instruction:

EFB pellet machine is our patent in China, high precision and good quality to be ensured.



The die mould made from Stainless steel and roller made from high wearable alloy steel, corrosion resistant, long lifetime. to make sure the high quality for everyone customer.


Increased ribs and thick casting, greatly enhances the mechanical strength and completely eradicate the shell breakage problems of pellet press.The gear box of our pellet press adopts high-quality gray cast iron, which makes the machine low noise, well shock absorption.



Application:



The  XGJ wood pellet making machine, with high pressure, can make pellets from different pressure ratio material: wood sawdust, agricultural straw, rice husk, sunflower shell, coconut husk, palm fiber, oil palm trunk,, EFB,  bamboo, alfalfa, grass, hay or other biomass. During pelletizing, no need any additives, DIN standard can be reached easlily.



Parameter:



Model

Power (kw)

Capacity (t/h)

Product spec (mm)

Weight (t)

Dimension (mm)

XGJ560

90+3+0.25+1.5

1-1.5

Φ4-12

6.1

2600x1300x2300

XGJ720

160+3+0.25+2.2

1.5-2

Φ4-12

9.2

2900x1300x2400

XGJ850

220+4+0.55+3

2-3

Φ4-12

14.5

3300x1400x3100

XGJ920

315+5.5+3+0.55+3

3-4

Φ4-12

18

3800x1680x3400


Advantages:



»   Feeding material vertically, not to be blocked;

»   Die mould static instlled vertically, Double layer, up and down for dual-use, reduce cost and increase efficiency;

»   Roller rotating high speed, generate centrifugal force,materials are centrifugal to around of die evenly;

»  Two lubricating system: High pressure cleaning filtration lubrication for driven device, ensure gear and maine shaft lubricating continuous;  Automatic intermittent oil supply, make sure roller bearing lubricating.

»   Reduce pressing room heat, dust abatement, to make the presing room heating in constant temperature effect,  reduce the components of high temperature grease overflow or carbon agglomerate, destroy the lubrication system.



After-sales service:

As a professional wood pellet making machine manufacturer in China, We take our responsibility to everyone customer very seriously.



Warning:


♦   The XGJ Series pellet mill and SKJ3 series pellet mill are YULONG band unique patents.other company similar machines displayed on alibaba are trespass , which are copy or imitation .only our company has the patent certificates.



♦   Furthermore,other companies were still stealing all the photos of our products,success cases,workshop,etc,and dispiaying them in their public website.before sending order , we greatly welcome you to our factory to check.



♦    We are seriously asking all the customer to boycott these copy or imitation machines from other comoanies , and don't be confuser or deceived by these improper action.
